KEY HIGHLIGHTSULx for NI LabVIEW is a library of VIs used with MCC devices to quickly develop data acquisition(DAQ) and control applications using LabVIEW. Includes a comprehensive library of graphical functions comprising all the power of our Universal Library and InstaCal software.Comprehensive library of VIs and example programs for NI LabVIEW™Seamless operation with most MCC hardware productsCompatible with NI LabVIEW versions 2010-2019Included with MCC DAQ SoftwareSupported Operating Systems: Windows® 10/8/7/XP, 32-bit or 64-bitDownload. Hi, I am using the ULx libraries to control a USB 1208LS DAQ device.

My goal is to synchronize my MC DAQ and other instruments in the lab using a TTL pulse that is read at the EXTTRIG pin on the USB 1208LS device. I've tested that this utility works on the DAQami software by selecting the external trigger option in the menu. However, when I attempt to program a Composite voltage reading and Composite trigger using External TTL, I receive an error 10124 'Composite trigger is not supported by the specified device.' I do not see how to set up trigger channels with external ttl and am unsure how to make this functionality work in LabView. I also cannot find an example anywhere in the ULx example folders for how EXTTRIG is supposed to by set up. Why does it tell me that this type of trigger is unsupported by the device? Is there a solution or an example for this?

Labview 2009 Crack

Thank you very much. Job Title: Research Assistant. Industry: AMO Physics - Precision spectroscopy. Application: Atomic excitation normalization by laser power monitoring.

The main cause of the error you see relates to “Composite”. None of the Composite VIs will work with the USB-1208LS hardware model, since that model cannot sample DI and CI channels synchronously (at the same clocked rate) as AI channels.Instead, start with the examples in Measure Voltage.llb, specifically the one named: ULx Acq&Graph Voltage-Int Clk-Dig Start.vi However, since the USB-1208LS hardware offers only level triggering (not edge triggering) you will have to make a change on the example’s block diagram. Select Basic Digital Level, and then specify either High or Low for the level. Then connect your trigger signal to pin 18 of the USB-1208LS. Once you Install the latest ULx driver, then open the following LLB of examples on your hard drive:C:Program FilesNational InstrumentsLabVIEW 2016examplesULxAnalog InMeasure Voltage.LLB. The best example to start with is named: ULx Acq&Graph Voltage-Int Clk.vi The example defaults to sampling a single channel, but from the front panel, following the instructions in the FAQ at the link below, you can browse and select multiple channels with the mouse:http://kb.mccdaq.com/KnowledgebaseArticle50375.aspx.

I want to use rs422 to send data to my devicei want to create boolean button to enable or disable another device (send 1 or 0 ) i want to use as example port 4 and 35 at the same time to do my function (my problem is how to define two ports at frist block of creating channle and use two ports at the same time )if you have example for seending data via rs422 give me link of itand i will tryHOW TO CHECK STATUS LED ON MINILAB 1008 BY USING LABViewthank you. Job Title: manager. Industry: ni. Application: using minilab to control devices. RS422 is an electrical standard of +/- 6V and is differential. The miniLAB 1008’s digital I/O bits are TTL/CMOS and single-ended.

Labview 2009 Serial Number Generator Pc Download

Therefore before even considering software, the miniLAB 1008 hardware is not suitable for communicating to RS422 devices.Strictly on the software question, looking at the 37 pin D connector, pin 4 is bit 6 of port B, while pin 35 is bit 2 of port A. Since you are using two different ports (A and B) you can use one for output and one for input. First, test each direction independently with our provided examples: ULx Read Dig Port.vi and ULx Write Dig Port.vi. Once you have both working independently, then combine the two programs. Since we do not promote our hardware as emulating a serial port, we do not have an example program that does so.

I think you are talking about using the digital outputs (8 on FirstPortA and 8 on FirstPortB) on the USB-1208LS, which is an older hardware model (that uses a real 8255 IC; newer models emulate the 8255). The issue you report is limited to just a couple of older DAQ models. A workaround is to, at the start of your app, write out benign values to both FirstPortA and FirstPortB, before you start to write new values to either port. Any further writes will not impact (reset) values written prior, since the direction of both ports were set (automatically for you by ULx) in the first two writes. Hello,I am using NI for LabVIEW and have a basic analog input set up to acquire data from an OMB-DAQ-2416-4AO. I set it up using the 'Using NI LabVIEW with Measurement Computing DAQ' video. If I set the sampling rate so that the data is collected in under about 10 seconds, there is no error.

If I set the rate and # of samples such that it takes longer to complete the acquisition, I get a 10003 error. There must be some sort of control that is looking for the data to be complete within a certain timeframe; is this adjustable?

If so how?Thank you very much. Job Title: Senior Engineer. Industry: Civil Engineering. Application: Basic data acquisition from LVDT voltage. HiIm having problems using labview 2015 with the ULx vis.When i try to us the Create Channel fuction from the palette tge program crashes. A window is shown with the inf:'error 100000 occurred at ULx Create Channel (AI-Voltage-Basic).vi5780001Possible reason(s):Measurements: Value passed to Task I7O In control is an empty I/O taskThe value must refer to a valid task.' I'm not wiring the task in terminal.im trying to make the tutorial exaclty the same as in: Getting started with NI LabVIEW, ULx and MCC analog Input Hardware, Part 1.

Labview 2009 Serial Number Generator

From your DB. Job Title: Programmer. Industry:.

Application. It sounds like you want to perform Analog Input, but you are presented only with Analog Output channels, or vice-versa. The USB-1208FS DAQ model you are using has both types of channels (though you should select AI Voltage, not AI Current input, since the USB-1208FS only measures voltage. What likely happened is that you changed the Create Channel VI’s channel type, from Analog Output to Analog Input, but you did so after wiring in a channel selector.

Try deleting the physical channel selector (purple) to the left of the Create Channel VI, and then recreating it. It should then locate the proper channels. Otherwise, try our function-specific examples that get installed as part of ULx. Hello Stephen - On September 25th, MCC released ULx driver version 2.12 that adds support for LabVIEW 2015. Below is a link to download the new support, along with a readme file covering installation.

This driver is fully released (not a beta), but the installer for it differs slightly from our regular MCCDAQ CD download, so be sure to read the short readme file before installing the software. Our larger (MCCDAQ CD) download is expected to be update in the November/December timeframe, once CD version 6.51 is released, at which time the following link will be deactivated.http://www.mccdaq.com/downloads/interimdownload/ULx2.12/. Hello Alex - You say you installed UL 6.35, but be sure you also installed ULx (ver 2.10 is part of the same MCCDAQ CD download).

To use MCC brand hardware in LabVIEW, you use our ULx VIs. Many examples are installed on your hard drive, but note that since the USB-2408 can measure both voltage and thermocouples, you need to run the voltage examples, not the temperature examples. Here are two FAQs that should be helpful: and http://kb.mccdaq.com/KnowledgebaseArticle50432.aspx.

Hello there,I have Labview (13). I install the latest version of MCC DAQ (V 6.35).I Installed USB-TC correctly. I configure the board using Instacal.

It can be seen from TracerDAQ and InstaCal.It seems that computer recognizes the board (USB-TC) very well. However, I have problem with Labview at first step. Developing a new VI, I put the first icon as 'ULx Creat Virtual Channel'. The second step, creating a channel, I used constant 'physical channel' and browsed through the list.

There is no sign of any channels or port in the list.To sum up, Labview cannot see any USB-TC channels.Please help me to resolve the problemMany thanks. Job Title: Research. Industry: Acedemia. Application: Temperature controller. I create my VI using the ULxforLabVIEW, I had no probles creating the VI, and I also create the EXE apparently without error but at the time of running the EXE I get a message saying 'the VI is not executable', I already try to fix the problem without success. I notice that at my proyect at the Dependecies field there is a vi called 'null' and it has a message saying 'Warning: has been deleted, renames or moved on disk', I haven't moved or deleted anything, and I notice that ir appeared after I create the EXE.Do you have a solution to my problem?.

Job Title: test eng. Industry:.

Application. MCC’s ULx for LabVIEW includes an example named ULx Acq Temperature Sample.vi which works fine with the USB-TC, but it only samples just one reading on only a single channel. Common needs are to expand the number of channels and to sample continuously. The USB-TC is only software paced, so a software timed loop is needed. You can configure the Create Channel VI to specify a range of channels, and then the Read VI can output a one-dimensional array one sample per channel. At the link below is such an example, that samples 5 channels at a 1 Hz rate. It does not graph the data, or log to disk, but you can use LabVIEW’s built in VIs to achieve those.http://kb.mccdaq.com/KnowledgebaseArticle50417.aspx.

Hello - The structure of the data array for our Tin function call is not a perfect match for what LabVIEW is looking for. The TinScan call places the data into one column, verses a row, with a column of data per channel. LabVIEW does not know how to parse this data. However, there are ways to get it to work and display multiple channels. For your convenience, I’m going to email you an example VI to help with your programming. Please check your inbox and let us know if we can help out in any other way. Hello Murray - There are three likely causes to the problem you report:1) You did not run InstaCal (Inscal32.exe) on your target machine, so that the DAQ device was recognized on the target machine.2) You did not follow the detailed steps listed in the ULx help file for: Building a stand-alone Windows application.

The results of which automatically pick up a “browse” file and deploy it on the target PC’s hard drive. The file name follows the following format: ULxBrowseXXX.LLB where, for example, XXX=110 for LabVIEW ver 11.3) You have duplicate copies of CBW32.DLL on the target PC’s hard drive. Hello Swank - If the LabVIEW version you just installed happens to be version 2013, be sure to install the very latest ULx (2.03), otherwise ULx won’t be installed for that LabVIEW installation.

Normally a copy of ULx is installed for each and every LabVIEW on the PC, from 8.5 upward. Therefore you don’t need to move ULx VIs from one version of LabVIEW to another. Also note that the ULx VIs installed were all saved in 8.5 format, so you will get warnings when you open them in a newer version of LabVIEW. Either ignore the warnings, or re-save all upon exiting.

BSODs are not at all common, and may be a sign that something is corrupt (best to uninstall and reinstall).
